VICTRON VENUS GX – CONTROL PANEL
The Venus GX provides intuitive control and monitoring for all products connected to it.
The list of Victron Energy® products that can be connected is endless: Inverters, Multis, Quattros, MPPT solar chargers, BMV battery monitors, Lynx Ion + Shunt and more
Warranty: 5 years
VICTRON VENUS GX ACCESSORIES FOR MONITORING SYSTEMS
Meter ET112 – 21324X – Single-phase energy meter – max 100A
Meter ET340 – 21586E – Three-phase Energy Meter – max 65A per phase
GX GSM – 22833A – GSM modem for GX products
GSP x GX GSM – 22834C – GSP active antenna for GX GSM
GX LTE 4G-E – 23783T – LTE-4G modem (Europe) for GX products
| Label | Value |
|---|---|
| Model | VENUS GX |
| SKU | 21201E |
| Remote console | Yes |
| VE.Direct | 2 dedicated isolated ports |
| VE.Can | 2 isolated parallel RJ45 sockets |
| VE.Bus | 2 isolated parallel RJ45 sockets |
| USB | 2 non-isolated USB host ports |
| Ethernet | Isolated RJ45 10/100/1000MB connector except screen |
| WiFi | integrated |
| Bluetooth Smart | future function |
| Slot micro SD card | SDHC cards up to max. 32GB |
| Second CAN-bus port | future function |
| Programmable Relay | 1 x NO / NC |
| Resistive tank level inputs | 3 |
| Temperature level inputs | 2 |
| Digital IO | future function |
| Dimensions HxLxP mm (“) | 45x143x96 (1.8x5.6x3.8) |
| Operating temperature | da -20 a +50°C |
| Safety | EN 60950 |
| EMC | EN 61000-6-3, EN 55014-1, EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
