VICTRON CERBO GX CONTROL PANEL
The Victron Cerbo Gx is all-new communication-centre allows you to always have perfect control over your system from wherever you are and maximises its performance.
5” accessory display GX Touch 50 – 23265U(optional)
Warranty: 5 years
VICTRON CERBO GX ACCESSORIES FOR MONITORING SYSTEMS
Meter ET112 – 21324X – Single-phase energy meter – max 100A
Meter ET340 – 21586E – Three-phase Energy Meter – max 65A per phase
GX GSM – 22833A – GSM modem for GX products
GSP x GX GSM – 22834C – GSP active antenna for GX GSM
GX LTE 4G-E – 23783T – LTE-4G modem (Europe) for GX products
| Label | Value |
|---|---|
| Model | CERBO GX |
| SKU | 23264S |
| LCD display and 7 buttons | GX Touch 50 (optional) |
| Remote console | Yes |
| VE.Direct | 3 |
| VE.Can | yes, not isolated |
| VE.Bus | 2 isolated parallel RJ45 sockets |
| Ethernet | Isolated RJ45 10/100/1000MB connector except screen |
| WiFi | integrated |
| Bluetooth Smart | YES |
| Slot micro SD card | SDHC cards up to max. 32GB |
| Programmable Relay | 2 x NO / NC DC up ti 30VDC: 6A DC up to 70VDC: 1A AC: 6A, 125VAC |
| Resistive tank level inputs | 4 |
| Temperature level inputs | 4 |
| Digital IO | 4 |
| Dimensions HxLxP mm (“) | 78x154x48 (3.1x6x1.9) |
| Operating temperature | da -20 a +50°C |
