ORION-TR SMART CC CONVERTERS – ISOLATED
Orion tr smart have with bluetooth enabled
Any Bluetooth enabled smart phone, tablet or other device can be used to monitor, to change settings and to update the charger when new software features become available.
Fully programmable
■ Battery charge algorithm (configurable) or fixed output.
■ Smart alternator compatibility: engine running detection mechanism.
Remote on-off
A remote on/off switch or relay contact can be connected to a two-pole connector. Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two pole connector can be switched to battery minus
| Label | Value |
|---|---|
| Models | 12, 24 V |
| Bluetooth Smart | Enabled |
ORION-TR SMART CC CONVERTERS - ISOLATED . models in comparison
| MODEL |
SKU |
INPUT VOLTAGE |
OUTPUT VOLTAGE |
MAX OUTPUT |
TEMPERATURE |
DIMENSIONS |
WEIGHT |
|---|---|---|---|---|---|---|---|
|
12/12-18 (220W) |
23260H |
8-17 |
12.2 |
25 |
18 |
130x186x70 (5.1x7.3x2.7) |
1,3 (3) |
|
12/24-10 (240W) |
23261K |
8-17 |
24.2 |
15 |
10 |
130x186x70 (5.1x7.3x2.7) |
1,3 (3) |
|
24/12-20 (240W) |
23262M |
16-35 |
12.2 |
25 |
20 |
130x186x70 (5.1x7.3x2.7) |
1,3 (3) |
|
24/24-12 (280W) |
23263P |
16-35 |
24.2 |
15 |
12 |
130x186x70 (5.1x7.3x2.7) |
1,3 (3) |
|
12/12-30 (360W) |
23149S |
10-17 |
12.2 |
40 |
30 |
130x186x80 (5.1x7.3x3.1) |
1,8 (4) |
|
12/24-15 (360W) |
23151C |
10-17 |
24.2 |
25 |
15 |
130x186x80 (5.1x7.3x3.1) |
1,8 (4) |
|
24/12-30 (360W) |
23162H |
20-35 |
12.2 |
45 |
30 |
130x186x80 (5.1x7.3x3.1) |
1,8 (4) |
|
24/24-17 (400W) |
23155L |
20-35 |
24.2 |
25 |
17 |
130x186x70 (5.1x7.3x2.7) |
1,6 (3.5) |
