EASYSOLAR-II GX – The all-in-one solar power solution

The Victron EasySolar-II GX integrates the following elements

■ A MultiPlus-II inverter/charger
■ A SmartSolar MPPT -Tr solar charge controller
■ A GX device with a 2 x 16-character display.
These elements come prewired together inside a single unit. This greatly simplifies most installations, saving time and money.
Display and Wi-Fi: The display reads battery, inverter and solar charge controller parameters. The same parameters can be accessed with a smartphone or other Wi-Fi enabled device. In addition, Wi-Fi can be used to set up the system and to change settings.
Solar charge controller included: the DC output of the SmartSolar MPPT is parallel wired with the DC connection of the MultiPlus-II
inverter/charger. The on/off mechanism of the MultiPlus-II also controls the SmartSolar MPPT.
GX device includes:

■ A BMS-Can interface. This can be used to connect to a compatible CAN-bus managed battery. Note that this not a VE.Can compatible port.
■ A USB port
■ An Ethernet port
■ A VE.Direct port
The GX device controls the MultiPlus-II and the SmartSolar MPPT with respectively a VE.Bus and a VE.Direct connection.
