COLOR CONTROL GX – SYSTEM MONITORING
The Color Control GX is the communication-centre of your installation. It offers at-a-glance live information, and lets you control all products connected to it.
The list of Victron Energy® products that can be connected is endless: Inverters, Multis, Quattros, MPPT solar chargers, BMV battery monitors, Lynx Ion + Shunt and more.
Warranty: 5 years
COLOR CONTROL GX ACCESSORIES FOR MONITORING SYSTEMS
Meter ET112 – 21324X – Single-phase energy meter – max 100A
Meter ET340 – 21586E – Three-phase Energy Meter – max 65A per phase
GX GSM – 22833A – GSM modem for GX products
GSP x GX GSM – 22834C – GSP active antenna for GX GSM
GX LTE 4G-E – 23783T – LTE-4G modem (Europe) for GX products
| Label | Value |
|---|---|
| Model | COLOR CONTROL GX |
| SKU | 68999W |
| LCD display and 7 buttons | yes |
| Remote console | Yes |
| VE.Direct | 2 dedicated isolated ports |
| VE.Can | 2 isolated parallel RJ45 sockets |
| VE.Bus | 2 isolated parallel RJ45 sockets |
| USB | 2 non-isolated USB host ports |
| Ethernet | Isolated RJ45 10/100/1000MB connector except screen |
| WiFi | optional |
| Slot micro SD card | SDHC cards up to max. 32GB |
| Programmable Relay | 1 x NO |
| Dimensions HxLxP mm (“) | 130x120x28 (5.1x4.7x1.1) |
| Operating temperature | from -20 to +50°C |
| Safety | EN 60950 |
| EMC | EN 61000-6-3, EN 55014-1, EN 61000-6-2, EN 61000-6-1, EN 55014-2 |
| Automotive | E4-10R-053535 |
