CHARGE CONTROLLER SOLAR MPPT STUDER

CHARGE CONTROLLER SOLAR MPPT VARIOSTRING VS-70

The VarioString VS-70 is a MPPT 70A solar charge controller. It is recommended for PV capacities up to 4.2kWp, and charges the battery with a maximum current
of 70A. The solar modules are connected in series to form one single string (up to 600V) connected to the VS-70, all this without special tools and with reusable connectors

CHARGE CONTROLLER SOLAR MPPT VARIOSTRING VS-120

The VarioString VS-120 is a MPPT 120A/48V solar charge controller. Fully isolated dual MPPT inputs up to 600V (Voc) (2×3.5kWp) or up to 900V (Voc) (7kWp) with MPPT inputs in series.

■ Reduces Balance of System costs: eliminates expensive wiring for parallel strings, saving wires, connectors, junction boxes, fuses, space, time etc
■ Safe, simple and trouble free connection: with SUNCLIX™ (Phoenix Contact “tool free”) PV connector
■ Fully protected against wrong wiring
■ Simplified safety rules by full isolation between PV and battery and between MPPT inputs
■ MPPT efficiency >99%: fast precise best in class tracking algorithm. World champion for efficiency in isolated converter with >98% conversion efficiency
■ Low self-consumption: < 1,2W in night mode
■ 4 step charger fully programmable for longer battery life
■ Optimal usage in a Xcom-LAN or Xcom-GSM
